MIL-DTL-45301E
TABLE VIII. Load application ratings. 1/
Nominal OD
Load - lb/in (N/m) of
Load - lb/in (N/m) of
tire size (in.)
nominal tire width
nominal tire width
at 10 mph (16 km/h) at 30 mph (48 km/h)
9
305 (53 410)
120 (21 015)
10
345 (60 415)
140 (24 515)
11
385 (67 420)
155 (27 145)
12
430 (75 300)
175 (30 645)
13
475 (83 180)
195 (34 150)
13 7/16
475 (83 180)
195 (34 150)
13 ½
495 (86 685)
205 (35 900)
20
790 (138 345)
340 (59 540)
21
840 (148 000)
365 (63 920)
22
885 (155 000)
385 (67 420)
23
935 (163 735)
410 (71 800)
24
985 (172 490)
435 (76 175)
25
1035 (181 245)
455 (79 680)
26
1085 (190 000)
480 (84 055)
27
1135 (198 760)
505 (88 435)
28
1185 (207 515)
530 (92 815)
29
1235 (216 270)
555 (97 190)
30
1285 (225 025)
580 (101 570)
31
1340 (234 660)
605 (105 945)
32
1390 (243 415)
630 (110 325)
1/ Tire load is found by multiplying the value given in the table by the nominal tire width.
Interpolation of table values is allowed.
4.9.1.4 Separation (drum) test.
4.9.1.4.1 Apparatus. To determine conformance to 3.5.5, the testing apparatus shall be
the same as that specified in 4.9.1.3.1.
4.9.1.4.2 Procedure. The tire, mounted on a hub and spindle assembly, shall be loaded
against the drum (see 4.9.1.3.1) and run continuously for 48 hours at 10 mph (16 km/h) and at
100 percent rated load capacity, as determined from table VIII for 10 mph (16 km/h). At the
conclusion of the test operation, the tire shall be examined externally and then internally, by
removal from the metal base and subsequent sectioning of the tire, to determine conformance
to 3.5.5.
