MIL-DTL-45301E
Tire size - Continued.
Army drawing number
24 x 2.38 (steel)
12313083
24 x 3-3/4
10919004
(was 24 x 5)
11636140
25-1/2 x 4-1/2
6576489
25 x 5.59
12274482
26 x 4-1/2
5621441
26 x 5-3/4
10887252
8762739
26 x 6
7013976
28 x 2-3/4
10954693
28 x 4-1/2
7764921
32-1/4 x 3-1/2
10891631
6.4 Part or Identification Number (PIN). The PIN to be used for tread elastomers
acquired to this specification are created as follows:
DTL - 45301
-
X
-
X
Class (see 1.2).
1
2
3
4
5
6
Group (see 1.2).
A
B
Specification number.
Prefix for detail specification.
6.5 Adequacy of physical property requirements. This specification is not intended to be
used without conducting the drum tests as specified in 4.9.1.3 and 4.9.1.4. The physical
properties specified herein do not fully describe all of the tread elastomer characteristics necessary
to meet the wheel performance requirements of this specification.
20
