MIL-DTL-45301E
g. If class 1 and class 2 compound layer thickness is other than specified (see 3.3.1).
h. If classes 3, 4, 5, and 6 tread elastomers will be furnished without anti-stick
material (see 3.3.2).
i. If class 1 elastomer should be cut other than as specified (see 3.4.1).
j. If class 2 die size and length is other than as specified (see 3.4.2).
k. If class 3 tread elastomer is other than in sheet form as specified (see 3.4.3).
l. If the inspection conditions are other than as specified (see 4.1.1).
m. If first article inspection is other than as specified (see 4.1.2).
n. If the testing location of the elastomer is other than as specified (see 4.1.2).
o. If testing of class 1 and class 2 dies are other than as specified (see 4.1.2).
p. If lot formation is other than as specified (see 4.1.3.2).
q. If the sampling for examination is other than as specified (see 4.1.3.3).
r. If conformance inspection is other than as specified (see 4.1.4)
s. Packaging requirements (see 5.1).
6.3 Wheel application. The tire size and corresponding Army drawing numbers for
wheels are:
Tire size
Army drawing number
9x6
5638473
10 x 3
5621440
10 x 5
5635856
11 x 3
5636637
12 x 3
8674928
12 x 4-1/8
6548131
13-7/16 x 1-11/16
10891645
13-1/2 x 3-1/2
8763030
13-1/2 x 3-3/4
8706067
5635849
18 x 2-1/2 (x 3-3/4)
10866037
20 x 6 x 16
5607928
20-1/2 x 6-1/4
5635844
22 x 1-11/16
10891655
(was 22 x 2)
22 x 1-3/4
10925778
10954177
22 x 6-1/4
5635861
23 x 1-1/4
9092158
24 x 2.12 (wide) (AL)
11678270 & 12269415
24 x 2-1/8
8763350
19
